2.5KV Fiberglass Sleeve Electrical Insulation Braided Sleeving Fiberglass High Temp Fiberglass Sleeving

Volsun's 2.5KV Fiberglass Sleeve Electrical Insulation Braided Sleeving is a highly effective solution for electrical insulation needs. Made from high-quality fiberglass material, this braided sleeving offers excellent protection against high temperatures. It is specifically designed for use in environments that are exposed to high temperatures and require exceptional electrical insulation.

This Fiberglass High Temp Fiberglass Sleeving can withstand temperatures of up to 1000°F. This means that it can handle extremely high temperatures without breaking down or degrading, making it ideal for use in high-temperature applications. The braided design of this Fiberglass Sleeve Electrical Insulation Braided Sleeving also provides additional protection against abrasion, cuts, and other hazards, which ensures that your electrical wires remain in good condition and are well-protected.

The 2.5KV Fiberglass Sleeve Electrical Insulation Braided Sleeving is incredibly easy to install, making it a great choice for electrical insulation applications. It can be easily cut to length so that it fits perfectly around your wires and cables. You can also easily slide the sleeving onto your wires and cables, which ensures that they are well-insulated and protected.

Thanks to its fiberglass construction, this Fiberglass High Temp Fiberglass Sleeving also boasts excellent resistance to chemicals and oils. It is highly resistant to solvents, acids, and other chemicals, which makes it a great choice for a wide range of applications. Whether you're working in an industrial setting, or you're simply looking for a durable and effective insulating solution for your home electrical system, this sleeving is sure to meet your needs

Product Overview

UL high voltage Silicone rubber fiberglass sleeve knitted fiberglass sleeve for wiring harness protection

Made of alkali-free glass fiber woven into a tube, coated with silicone rubber on the outer layer of the tube, and then cured. It has high dielectric strength, good flexibility, heat aging resistance, oil resistance, flame retardant, and temperature resistance up to 200 degree. Widely used in circuit insulation protection for new energy vehicles, special vehicles, rail transit, military aerospace, etc

Features:

1. Operating temperature:-40°C~200°C

2. Environmental standard: RoHS, REACH

3. Color :Nature, White, Black, Red, Yellow, Blue, Green, Orange, other colors are available

4. Flame retardant rating: HB

5. Rated voltage: 1.5KV,2.5KV,4.0KV,7.0KV

PRODUCT SPECIFICATIONS

Items	Technical Parameters	Reference Standard
Appearance	No glue leakage, cracking, etc	GB/T 7113.1-2014
Coating hydrolysis	No coating displacement, adhesion, etc	GB/T 7113.2
Cold bending test	-40℃，4h，No cracks, coating peeling and delamination	IEC60684
Temperature	-40℃～200℃	UL1441
Flame retardant rating	HB	UL94
Breakdown voltage	Reference standard	GB/T 1408-2016
Heat Resistance	250℃±5, 24h, No droplets, no flow marks, no cracking	JB/T 7093 2015

Dimensions

I.D. mm			Wall thickness mm				Wall Thickness（mm）			Package
Size	Tolerance	1500V	2500V	4000V	7000V	M/Roll
Φ2.0	-0.10～0.25	0.35±0.1	0.40±0.1	0.45±0.1	0.5±0.1	100
Φ2.5	-0.10～0.25	0.35±0.1	0.40±0.1	0.45±0.1	0.5±0.1	100
Φ3.0	-0.10～0.25	0.35±0.1	0.40±0.1	0.45±0.1	0.5±0.1	100
Φ3.5	-0.10～0.35	0.4±0.1	0.45±0.1	0.50±0.1	0.55±0.1	100
Φ4.0	-0.10～0.35	0.4±0.1	0.45±0.1	0.50±0.1	0.55±0.1	100
Φ4.5	-0.10～0.35	0.4±0.1	0.45±0.1	0.50±0.1	0.55±0.1	100
Φ5.0	-0.10～0.35	0.4±0.1	0.45±0.1	0.50±0.1	0.55±0.1	100
Φ5.5	-0.10～0.40	0.45±0.1	0.50±0.1	0.55±0.1	0.60±0.1	100
Φ6.0	-0.10～0.40	0.45±0.1	0.50±0.1	0.55±0.1	0.60±0.1	100
Φ7.0	-0.10～0.50	0.45±0.1	0.50±0.1	0.55±0.1	0.60±0.1	100
Φ8.0	-0.10～0.50	0.45±0.1	0.50±0.1	0.55±0.1	0.65±0.1	50
Φ9.0	-0.10～0.50	0.45±0.1	0.50±0.1	0.55±0.1	0.65±0.1	50
Φ10.0	-0.20～0.70	0.50±0.15	0.55±0.15	0.65±0.15	0.7±0.15	50
Φ11.0	-0.20～0.70	0.50±0.15	0.55±0.15	0.65±0.15	0.7±0.15	50
Φ12.0	-0.20～0.70	0.50±0.15	0.55±0.15	0.65±0.15	0.7±0.15	50
Φ13.0	-0.30～0.80	0.55±0.15	0.60±0.15	0.70±0.15	0.75±0.15	50
Φ14.0	-0.30～0.80	0.55±0.15	0.60±0.15	0.70±0.15	0.75±0.15	50
Φ15.0	-0.30～0.80	0.55±0.15	0.60±0.15	0.70±0.15	0.75±0.15	50

Company Show

Suzhou Volsun Electronics Technology Co., Ltd. was founded in 2006. We keep focusing on the R&D, production and sales in insulation, sealing & protection solutions for over 18 years

Quality is our culture. Volsun has a modern quality management system, which has passed a series of quality system certification such as IATF16949, ISO9001 etc. And we have gained some advanced titles such as Jiangsu famous scientific and technical corporation, China new high-tech enterprise etc. have independent intellectual property rights, 88 patents and 97 product certifications

Up to now, Volsun cooperated with customers from 88 countries, we offer suitable sealing, waterproof solutions for some well-know enterprises in communication, Automobile, Power industry etc

Certificate

Packing & Delivery

Production View

Production View

Delivery

Trade terms	FOB, EXW, CIF, DDU, DDP, CFR
Payment terms	T/T, L/C, Negotiable
Supply capability	1,000,000 mts per month
Lead time	Usually 2-3 working days
Shipment	Express, Air, Sea
Port	Shanghai, Ningbo, Shenzhen
Sample availability	Yes
Sample time	Usually 1-2 days
Packaging	Normal: Plastic bag & Carton & Pallet Special: Customized packing
