100-Pack Thermal Conductive Silicone Rubber Thermal pads Silicone Thermal Transfer Pads for GPU/CPU/VGA/IC/LED

The Volsun’s 100-Pack Thermal Conductive Silicone Rubber Thermal pads are the perfect solution for anyone looking to improve the performance and longevity of their electronic devices. These thermal pads are made from high-quality silicone rubber materials that are designed to provide excellent thermal conductivity while remaining flexible and easy to install.

The set includes 100 thermal pads that can be used on a variety of different electronic components, including GPUs, CPUs, VGAs, ICs, and LEDs. These thermal transfer pads can help to dissipate heat more efficiently, allowing your devices to run at cooler temperatures and reducing the risk of damage from overheating.

One of the standout features of the Volsun’s Thermal Conductive Silicone Rubber Thermal pads is their ease of use. The pads have a self-adhesive backing, making them easy to apply to your devices without the need for any additional adhesive or mounting hardware. Plus, the pads are pre-cut to fit common electronic component sizes, so you won't need to waste time trimming them to size.

Another benefit of these thermal pads is their durability. The silicone rubber material is resistant to high temperatures, so it can withstand the heat generated by even the most demanding applications. The pads are also non-conductive, so you won't need to worry about any electrical shorts or other issues that can arise with metallic thermal transfer materials.

If you're looking for a cost-effective way to improve the thermal performance of your electronic devices, the Volsun’s 100-Pack Thermal Conductive Silicone Rubber Thermal pads are an excellent choice. They provide excellent thermal conductivity, are easy to install, and are durable enough to last for years of use. Whether you're a DIY enthusiast or a professional electronics technician, these thermal pads are sure to exceed your expectations

Product Overview

RoHS Compliance Flame Retardant Organic Silicone Rubber Thermal Conductive Pad

Description
VS-GP1501 silicone thermal pads achieve low interfacial thermal resistance at relatively low pressures, with excellent thermal conductivity, thermal stability, flexibility and resilience. Also, it is safe and reliable to use. Applied between the power device and the cooling aluminum sheet or the machine shell, the air can be effectively excluded to achieve good thermal conductivity and filling effect

Features

*  Continuous operating temperature：-40℃~+200℃
*   High thermal conductivity, low thermal resistance
*  Excellent surface wettability and resilience
*  Excellent flame retardant
*  Multiple thickness selection, wide application range

*   Environmental protection standard: RoHS, REACH

Click to get free sample

PRODUCT SPECIFICATIONS

Item	Typical Data	Test Method
Standard color	Grey	Visual
Density (g/cm3)	1.9	ASTM D792
Thickness (mm)	0.5~5.0	ASTM D374
Hardness (Shore OO)	25~70	GB/T 531.1-2008
Tensile Strength(KPa)	≥80	GB/T 528-2009
Elongation at break (%)	≥50	GB/T 528-2009
Thermal conductivity (W/m·k)	1.5±0.2	ASTM D5470
Flame Retardancy Rating	V-0	UL94
Breakdown Voltage（kV/mm）	（kV/mm）	ASTM D149
Volume resistivity	≥1.0×10 14 Ω·cm	ASTM D257

Dimensions are customizable and available on request

Instructions

*  Clean the surface of the substrate to be installed before use
*  Select suitable products based on the dimensions of the installation position

Precautions

*   The environment should be free of large debris or other pollutants to avoid affecting the installation effect and protective performance of the materials

* The specifications of the product should be similar to the dimensions of the installation position, and the deviation should not be too large

Storage conditions Shelf life

*  Storage Temperature: 0℃~40℃

*  Relative humidity: RH＜ 80%
*   Shelf life: 12 months from the production date

Detail Show

Applications

GPU/CPU Chip

New Energy Vehicle Battery Packs

Heat Dissipation Module

Company Show

Suzhou Volsun Electronics Technology Co., Ltd. was founded in 2006. We keep focusing on the R&D, production and sales in insulation, sealing & protection solutions for over 18 years
Quality is our culture. Volsun has a modern quality management system, which has passed a series of quality system certification such as IATF16949, ISO9001 etc
Up to now, Volsun cooperated with customers from 88 countries, we offer suitable sealing, waterproof solutions for some well-known enterprises in communication, Automobile, Power industry etc

Certifications

Product packaging

Packing & Loading-1

Packing & Loading-2

Abroad Exhibition

Las Vagas AAPEX

Moscow Expo

Hannover Messe

FAQ

Q 1. How long is the payment term

A: We accept T/T 50% deposit and 50% balance against B/L or L/C copy at sight, also accept Western Union, VISA and Paypal

Q 2. What is the normal lead time for product orders

A: The average lead time for prototype/first piece is 7~10 days, if tooling is involved, the lead time for production tooling is 10 days, and the average production time after sample approval is 2-3 weeks

Q 3. What is your standard packaging

A: All goods will be packed in cartons and loaded on pallets. Special packing methods are acceptable when needed

Q 4. Can you tell us the monthly production capacity of your products

A: It depends on the model, we produce more than 1500 tons of rubber materials per month

Q 5. What kind of certificates do you have
A1: We have ISO9001:2015, IATF16949:2016, ISO14001:2015, ISO45001:2018 certified

A2: We have various rubber compounds approved by UL, ROHS and REACH

Q6: How to check the quality of bulk order
A1: We provide pre-production samples to all customers before mass production if needed.

A3: We accept third-party inspection, such as SGS, TUV, INTERTEK, BV, etc

Q 7: Can you provide customized service
A: Yes, we accept customization and can produce products in different sizes, packaging, colors according to requirements
